Size : 72×72
Panel Cutout : 68×68
Display : Upper : 7 Segment, 4 Digit, 0.4″, Red LED for Meter Lower : 7 Segment, 4 Digit, 0.4″, Green LED for Meter Per Minute
Size : 96×96
Panel Cutout : 92×92
Display : Upper :7 Segment, 4 Digit, 0.56″, Red LED for Meter Lower : 7 Segment, 4 Digit, 0.4″, Green LED for Meter Per Minute
NPN/PNP Proximity Switch/Micro Switch(Configurable)
0~9999 Count
Output 1 : 1- Relay,
Rating : 1C / O , 5A, 230 Vac
SSR/Buzzer : 12V DC (30m A DC) Approximately (Factory Set)
Single Set Point
99.9 Sec(Configurable)
Up / Down Counting Factory set
Non Volatile Memory
Auto/ Manual Reset facility from Back
230V AC, 50 Hz Linear
H41P : 100~250 ~Ac/Dc, 50Hz/60Hz, SMPS
ABS Polycarbonate
0 to 55 Degree Celsius
Up to 95% RH Non Condensing
