Size : 48×48
Panel Cutout : 44×44
Display : Upper : 7 Segment, 4 Digit, 0.39″, Red LED for Process Value Lower : 7 Segment, 4 Digit, 0.28″, Green LED for Set Value
Size : 72×72
Panel Cutout : 68×68
Display : Upper : 7 Segment, 4 Digit, 0.56″, Red LED for Process Value Lower : 7 Segment, 4 Digit, 0.4, Green LED for Set Value
Size : 96×96
Panel Cutout : 92×92
Display : Upper : 7 Segment, 4 Digit, 0.56″, Red LED for Process Value Lower : 7 Segment, 4 Digit, 0.4, Green LED for Set Value
Sensor : J/K/PT.100 (2W/ 3W) Configurable
Range : (0-600) K(0-1200), Pt-1002W/3W(-99-400, -99.9 to 400.0) Degree Celsius
Output 1 : 1- Relay,
Rating : 1C / O , 5A, 230 Vac
SSR/Buzzer : 12V DC (30 mA DC) Approximately (Factory Set)
1 Set Points
Auto Tune PID / On-Off Configurable
Heating
G41X : 100-250 Vac/DC, 50/60Hz , SMPS
Other : 230Vac 50 Hz LPS
± 1% of FSD
J&K 1°C Fix, Pt-100 2W/3W 1°C/0.1°C
ABS Polycarbonate
0 to 55 Degree Celsius
Up to 95% RH Non Condensing
